405nm UV Led Module 3D Printer uva Curing COB 30W 60W 90W 365nm 395nm lampara

Brand Name : YM

Model Number : UV LED COB 90W

Certification : High-tech Enterprise Certificate

Place of Origin : CHINA

MOQ : Negotiate

Price : Negotiate

Payment Terms : T/T

Supply Ability : 10000

Delivery Time : 10-15 work days

Packaging Details : Carton

Product Name : COB UV LED 90W

Module Size : 50mm*45mm

Luminous Size : 20mm*20mm

Voltage : 34-38V

Current : 1.5-2.1A

Wavelength : 365nm, 385nm, 395nm, 405nm

Series-parallel : 10 Series-3 parallel

Warranty : 1 Year

Contact Now

COB UV LED Module Product Description

The product can be applied with either Water-cooling or wind-cooling method.
Other curing size and voltage can be designed according your requirment, inluding mix

wavelenth special wavelenth and curing size.
High efficiency and low consumption.
Apply in various printing industries.

Advantages

long life: the service life is more than 10 times that of the traditional lamp machine.
cold light source, no heat radiation, the surface temperature of the illuminated product is low, solving the traditional heat injury problem. Particularly suitable for LCD edge sealing, film printing, etc.
the heat is small, can solve the problem of large heat generation of traditional equipment.
Instant lighting, no need to preheat to instantly achieve 100% power UV output.
The service life is not affected by the number of opening and closing.

Item	High Power COB UV LED Module
Power	90w
Color	UV
Diode Brand	DC, LG
Diode type	COB
Lens Material of Diode	COB
Module size	50mm*45mm
Luminous Size	20mm*20mm
Wavelength	365nm,385nm,395nm,405nm
Voltage	34-38V
Current	1.5-2.1A
Chip Material	Epileds
Encapsulation process	COB
Lifespan (hours)	20000
Warranty	year
Place of Origin	Guangdong, China

Characteristic

1.Inquiry and consulting support

2. 24-hour on-line services

3.Machine with uv led curing system printing effect video is available for you

4. You're warmly welcome to visit our factory.

5. You can receive customized production and packing.

6.12 months trouble-free warranty and online support
